| Hot Water Flow Rate (L/h) | 32 | 44 | 62 | 76.6 | 88.8 | 117.6 |
| Heating Capacity (kW) | 7.5 | 10.5 | 15 | 18.5 | 22 | 29.2 |
| Rated water output @ 55°C (L/h) | 1070 | 1500 | 2142 | 2642 | 3142 | 4171 |
| Rated water output @ 60°C (L/h) | 970 | 1371 | 1961 | 2421 | 2871 | 3811 |
| Rated water output @ 65°C (L/h) | 873 | 1234 | 1764 | 2179 | 2584 | 3431 |
| Hot Water Outlet Temp (°C) | 55–65 | 55–65 | 55–65 | 55–65 | 55–65 | 55–65 |
| Rated Input Power (kW) | 2.3 | 3.2 | 4.5 | 5.5 | 6.5 | 8.6 |
| Rated Input Current (A) | 3.5 | 4.8 | 6.8 | 8.5 | 10.2 | 14.0 |
| Power Supply |
| Type | 220V / 1Phase / 50Hz |
| Compressor |
| Type | Fully enclosed type |
| Brand | PANASONIC / HITACHI / DANFOSS |
| Start Method | Direct Start |
| Quantity (No) | 1 | 1 | 1 | 1 | 1 | 2 |
| Water Proof Grade | IP 24 |
| Electric Shock Protection Type | I |
| Heat Exchanger |
| Type | High efficiency double wall heat exchanger |
| Quantity | 1 | 1 | 1 | 1 | 1 | 2 |
| Material | Micro Groove Tube |
| Evaporator | Hydrophilic Aluminum |
| Refrigerant | R134a | R134a | R134a | R407c | R407c | R407c |
| Expansion Valve | Submersive Sine Wave Electronic expansion valve |
| Water Side |
| Inlet Pipe Size (mm) | 25 | 25 | 25 | 40 | 40 | 40 |
| Outlet Pipe Size (mm) | 25 | 25 | 25 | 40 | 40 | 40 |
| Pipe Type | Low carbon copper pipe with hydrophilic foil |
| Fan |
| Type | Household |
| Speed (RPM) | 850 |
| Input Power (W) | 30 | 30 | 80 | 80 | 80 | 96 |
| Quantity | 1 | 1 | 1 | 1 | 1 | 2 |
| Protections |
| Under / Over voltage protection, Under / Over current protection, Open phase, Phase reversal, Phase imbalance, Compressor high discharge temperature protection, Compressor high discharge pressure protection, Compressor over current protection, Anti-freeze protection |
| Noise (DBA) | ≤ 55DB(A) |
| Net Weight (kg) | 95 | 100 | 130 | 160 | 200 | 270 |
| Cabinet | Galvanized steel powder coated |
| Dimensions (mm) |
| Width | 920 | 920 | 1000 | 1250 | 1300 | 1400 |
| Depth | 520 | 520 | 560 | 560 | 600 | 680 |
| Height | 790 | 790 | 910 | 910 | 1010 | 1010 |
